Figure 1. The VSP tool shown above consists of 12 individual sondes linked by an electronic cable and terminated with a logging cable head. The distance between each sonde can be 10, 15 or 20 m. Each sonde contains three orthogonal geophones (two horizontal and one vertical) and a single hydrophone. A hydraulically powered locking arm (shown retracted) ensures that the geophone package is secured against the borehole wall (Courtesy of CGG).
(1 of 8)
Figure 1. The VSP tool shown above consists of 12 individual sondes linked by an electronic cable and terminated with a logging cable head. The distance between each sonde can be 10, 15 or 20 m. Each sonde contains three orthogonal geophones (two horizontal and one vertical) and a single hydrophone. A hydraulically powered locking arm (shown retracted) ensures that the geophone package is secured against the borehole wall (Courtesy of CGG).
